Metric Architectural Plumbing Plan Views Template 9383TAM

Metric Architectural Plumbing Plan Views Template 9383TAM
Click to Enlarge
Item # 21395
MFG Part #: 9383TAM
Regular price:$8.25
Sale price:$6.35
You Save 23%
Qty
Template Metric Architectural Plumbing – Plan Views: Contains: American Standard lavatory and kitchen fixtures, institutional products, circles, squares, triangles, arrow. Scales: 1:200, 1:100, 1:50. Size: 15cm x 25cm x 5mm.
